Push-in RTD temperature probes(TM1101)
|
|
|
|
Applications：
The Push-in RTD
temperature probes are used to measure the temperature of gases or liquids,
including HVAC, Refrigeration equipments, Heaters, Ovens, Mechanical
equipments and Experimental facilities, etc.
|
|
Technical data:
Connecting cable: PVC, temperature
range:-5℃~+85℃
Silicone,
temperature range:-50℃~+180℃
Teflon, temperature
range -50℃~+260℃
Glass Fiber,
temperature range:-50℃~+350℃
Protection tube: Stainless steel
304/316, OD=4mm,5mm, 5.2mm,6mm
Sensor element: Pt100, Pt500, Pt1000 meets IEC 751
Tolerance :
Class B: △t=±(0.30 + 0.005 |t| )℃
Class A: △t=±(0.15 + 0.002 |t| )℃
Response time：t0.9 approx. 10secs, in water 0.2
m/sec, diameter 6mm
