Swaged RTD
temperature probes (TM1104)
Applications：
The swaged RTD
temperature probes are used to measure the temperature of gases or liquids,
including Heaters,Ovens, Mechanical equipments and Experimental facilities
etc.
|
|
Technical data：
Connecting cable: PVC, temperature
range:-5℃~+85℃
Silicone,
temperature range:-50℃~+180℃
Teflon, temperature
range -50℃~+260℃
Glass Fiber,
temperature range:-50℃~+350℃
Protection tube: Stainless steel
304/316, OD=4mm,
5mm,6mm
Sensor
element: Pt100 meets IEC 751
Tolerance
: Class B: △t=±(0.30 + 0.005 |t| )℃
Class A: △t=±(0.15 + 0.002 |t| )℃
Response time：t0.9 approx. 4secs, in water 0.2 m/sec,
diameter 4mm
