Slot RTD temperature probes(TM1109)
Applications：
The Slot RTD temperature probes
are used to measure the temperature of the engine coil. It is mainly used
to monitor coil temperature against damage.
|
|
Technical data:
Sensor element:
Pt100, Pt500, Pt1000 meets IEC 751
Tolerance :
Class B: △t=±(0.30 + 0.005 |t| )℃
Class A: △t=±(0.15 + 0.002 |t| )℃
Pressure range：2.5KV or 4KV（optional）
Operating voltage: ≤60V
Operating current：≤1mA
Connecting cable:PTFE(core),
Silicone(sheath)
Measuring range:-50℃~+180℃
