Applications：
The Pipeline RTD
temperature probes are used to measure the temperature of pipe wall or
round surface. It can be fixed with cable ties. Heat paste can be used to
strengthen heat conduction. It is recommended to adopt measurements of heat
preservation and insulation in case direct heat radiation affects the
measure accuracy.
|
|
Pipeline RTD temperature probes （TM1111)(1)
Technical data
Connecting cable: Silicone,
temperature range:-50℃~+180℃
Teflon, temperature
range -50℃~+260℃
Glass Fiber,
temperature range:-50℃~+350℃
Protection tube: Stainless steel
304/316
Sensor element:
Pt100, Pt500, Pt1000 meets IEC 751
Tolerance :
Class B: △t=±(0.30 + 0.005 |t| )℃
Class A: △t=±(0.15 + 0.002 |t| )℃
