Form J Screw-in RTD temperature probes （TM1402)
|
|
|
|
Applications:
HVAC, Compressors,Refrigeration
equipments, experimental facilities, mechanical equipments, ovens etc.
|
|
Technical data
Protection tube：stainless steel 304/316
Sensor element:
Pt100, Pt500, Pt1000 meets IEC 751
Tolerance : Class
B: △t=±(0.30
+ 0.005 |t| )℃(standard)
Class A: △t=±(0.15 + 0.002 |t| )℃
Protection Class： IP54 or IP65
Response time：t0.9 approx. 5secs, in water 0.2 m/sec,
diameter 4mm
接線圖 Wiring diagram 鉑電阻 RTD
單支2線 1x2-wire單支3線 1x 3-wire雙支4線 2x4-wire
單支4線 1x4-wire安裝螺釘 mounting screw 紅色標記 red
mark
